Today’s high performance ventilators and resuscitators need high performance regulators to optimize their output capabilities. That’s why our O-Two Oxygen Regulators are the perfect choice to meet the needs of the respiratory impaired patient or those in respiratory arrest. The all brass (or aluminum body/brass core) construction of these high quality regulators improves product safety by reducing the risk of exacerbating a regulator fire should it occur.
With an optional oxygen therapy flow rate range of 0-15 L/min or 0-25 L/min you can choose the range that most suits the needs of your patient in respiratory distress who requires oxygen therapy. For powering oxygen equipment, different configurations of pressure outlets are available. Input connections of either nut and stem or pin indexed yoke are available as well as regulator for Entonox® analgesic gas.
By providing consistent output pressure and flow, the O-Two range of Oxygen Regulators ensures the maximum operating time on any cylinder. Built for the demands of the pre-hospital and in-hospital markets, the O-Two Regulator series provides unbeatable quality and performance.
Features and Applications of O-Two Regulators
Therapy Flowrate Settings:
0, 1, 3, 4, 6, 8, 10, 12, 15, 20, 25
Alternative Flowrate Settings:
0.5, 1, 2, 3, 4, 5, 6, 8, 9, 12, 15
Gauge Accuracy:
2% of full scale + 8% of reading
Operating Inlet Pressure:
500 to 3000 PSI (34.5 to 206.8 BAR)
Nominal Outlet Pressure:
60 PSI (4.14 BAR)
Storage Temperature:
-28 to 60°C (-18.4 to 140°F)
Operating Temperature:
-18 to 50°C (-0.4 to 122°F)
Maximum High Flow Capability (9/16 In Diss Outlet):
> 180 L/min (one port open)
Size (Incl., Gauge And Pressure Outlet):
Inches: (l x h x w) 6 x 3 x 1.5 (approx.) | Milimiters: (l x h x w) 152 x 76 x 38 (approx.)
Weight (Approx.):
27 oz / 748 g
This product has a five year warranty against manufacturers defects.
Pressure Regulators Specifications
Adjustable Therapy Flow Regulators
01RO01003-A
Therapy Flow 0 – 25 L/min, Barbed Outlet Aluminum Shell, Brass Core Pin-Indexed Yoke
Each
01RO01002-A
Therapy Flow 0 – 15 L/min, Barbed Outlet Aluminum Shell, Brass Core Pin-Indexed Yoke
Each
01RO01003-B
Therapy Flow 0 – 25 L/min, Barbed Outlet All Brass Pin-Indexed Yoke
Each
01RO02003-B
Therapy Flow 0 – 25 L/min, Barbed Outlet All Brass 540 Nut & Stem
Each
Pressure Regulators
01RO01010-B
Brass Pin-Indexed Yoke with 1 x 9/16” Self-Sealing DISS Outlet (No Therapy Flow)
Each
01RO01020-B
Brass Pin-Indexed Yoke with 2 x 9/16” Self-Sealing DISS Outlets (No Therapy Flow)
Each
01RO02010-B
Brass 540 Nut & Stem with 1 x 9/16” Self-Sealing DISS Outlet (No Therapy Flow)
Each
01RO02020-B
Brass 540 Nut & Stem with 2 x 9/16” Self-Sealing DISS Outlets (No Therapy Flow)
Each
Combined Flow & Pressure Regulators
01RO01023-B
All Brass Pin-Indexed Yoke with Therapy Flow 0 – 25 L/min, Barbed Outlet – with 2 x 9/16 Self-Sealing DISS Connectors
Each
01RO01023-MRI
MRI Brass Pin-Indexed Yoke with Therapy Flow 0 – 25 L/min, Barbed Outlet, 2 x 9/16 Self-Sealing DISS Outlets
Each
01RO02023-B
All Brass 540 Nut & Stem with Therapy Flow 0- 25 L/min, Barbed Outlet – with 2 x 9/16 Self- Sealing DISS Connectors
Each
Spare Parts
01OR1002-CS
Brass/Viton Yoke seal
Case/10
01OR1007
Pressure Gauge 3000 PSI (200 bar)
Each
02RT5400-10
Nylon Cylinder Wrench w/ strap
Case/10
17MP4118
Post Valve plug with dust cap
Case/25
